| Min Bore Diameter (Decimal Inch) | 0.3000" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Inch) | 1-1/4" |
| Max Bore Depth (Decimal Inch) | 1.250" |
| Projection (Decimal Inch) | 0.1100" |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Centerline Offset (Decimal Inch) | 0.1438" |
| Corner Radius (Decimal Inch) | 0.008" |
| Neck Diameter (Decimal Inch) | 0.1900" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.50" |
| Tooth Width (Decimal Inch) | 0.0920" |
