| Min Bore Diameter (Decimal Inch) | 0.3000" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Decimal Inch) | 1.600" |
| Projection (Decimal Inch) | 0.0500" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Decimal Inch) | 0.1125" |
| Offset (Inch) | 1/8" |
| Offset (Decimal Inch) | 0.125" |
| Corner Radius (Decimal Inch) | 0.006" |
| Face Dimension (Decimal Inch) | 0.189" |
| Length from Holder (Decimal Inch) | 1.853" |
| Neck Diameter (Inch) | 1/4" |
| Neck Diameter (Decimal Inch) | 0.2500" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.00" |
| Split Length (Decimal Inch) | 0.220" |
| Tooth Width (Decimal Inch) | 0.1420" |
