Product Specifications
| Min Bore Diameter (Inch) | 5/16" |
| Min Bore Diameter (Decimal Inch) | 0.3120" |
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Projection (Decimal Inch) | 0.1000" |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Radius (Inch) | 1/32" |
| Radius (Decimal Inch) | 0.0310" |
| Face Dimension (Decimal Inch) | 0.301" |
| Length from Holder (Decimal Inch) | 0.853" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.00" |
| Split Length (Decimal Inch) | 0.225" |
| Tooth Width (Inch) | 1/16" |
| Tooth Width (Decimal Inch) | 0.0620" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Projection (Decimal Inch):
0.1000"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.00"
Finish/Coating:
Uncoated
Width (Decimal Inch):
0.062"
Minimum Groove Diameter (Decimal Inch):
0.322"
Radius (Inch):
1/32"
Radius (Decimal Inch):
0.0310"
Grooving Tool Type:
Face Grooving
Ships:
From Partner Facility
IsDiscontinued:
