Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.0800" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Inch) | 3/8" |
| Max Bore Depth (Decimal Inch) | 0.375" |
| Projection (Decimal Inch) | 0.0250" |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Centerline Offset (Decimal Inch) | 0.0525" |
| Radius (Decimal Inch) | 0.0100" |
| Face Dimension (Decimal Inch) | 0.094" |
| Length from Holder (Decimal Inch) | 0.590" |
| Neck Diameter (Decimal Inch) | 0.0550" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.50" |
| Tooth Width (Decimal Inch) | 0.0200" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Projection (Decimal Inch):
0.0250"
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.50"
Finish/Coating:
AlTiN
Width (Decimal Inch):
0.020"
Radius (Decimal Inch):
0.0100"
Minimum Bore Diameter (Decimal Inch):
0.0800"
Maximum Bore Depth (Decimal Inch):
0.375"
Grooving Tool Type:
Full Radius
Ships:
From Partner Facility
IsDiscontinued:
