Product Specifications
| Cutter Diameter (Inch) | 3/16" |
| Cutter Diameter (Decimal Inch) | 0.1875" |
| Coating | Uncoated |
| Flutes | 4 |
| Length of Cut (Decimal Inch) | 0.150" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Offset (Decimal Inch) | 0.104" |
| Radius (Decimal Inch) | 0.0938" |
| Neck Diameter (Decimal Inch) | 0.1500" |
| Neck Length (Decimal Inch) | 0.350" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.00" |
| Overall Reach (Decimal Inch) | 1.200" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Mill Diameter (Inch):
3/16"
Mill Diameter (Decimal Inch):
0.1875"
Number of Flutes:
4
Length of Cut (Decimal Inch):
0.150"
Material:
Carbide
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.00"
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Finish/Coating:
Uncoated
Overall Reach (Decimal Inch):
1.200"
Application:
Undercutting, Deburrring & Multi-Axis Machining
Ships:
From Partner Facility
