| Min Bore Diameter (Decimal Inch) | 0.3650" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Inch) | 1-1/4" |
| Max Bore Depth (Decimal Inch) | 1.250" |
| Projection (Decimal Inch) | 0.0950" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Decimal Inch) | 0.1775" |
| Radius (Inch) | 1/16" |
| Radius (Decimal Inch) | 0.0625" |
| Angled Projection (Decimal Inch) | 0.171" |
| Face Dimension (Inch) | 3/16" |
| Face Dimension (Decimal Inch) | 0.188" |
| Neck Diameter (Decimal Inch) | 0.2700" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.50" |
| Split Length (Inch) | 3/8" |
| Split Length (Decimal Inch) | 0.375" |
| Tooth Width (Inch) | 1/8" |
| Tooth Width (Decimal Inch) | 0.1250" |
