Product Specifications
| # Manufacturer Number | 1315197 |
| Diameter (Inch) | 7/16" |
| Shank (Inch) | 13/64"" |
| Flute Length (Inch) | 3-3/4" |
| Overall Length (Inch) | 5-7/8" |
| Drill Point Angle | 135 |
| Number of Flute | 2 |
| Material | Powdered Metal HSCO Steel |
| Finish / Coating | Tin+TiCN |
| Coolant Through | Yes |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Flute Type:
Conventional Spiral
Drill Bit Size (Inch):
7/16";Drill Bit Size (Decimal Inch)=0.4375""
Drill Bit Size (mm):
11.11mm
Drill Point Angle:
135 Degree
Overall Length (Inch):
5-7/8";Overall Length (Decimal Inch)=5.8750""
Overall Length (mm):
149.23mm
Cutting Direction:
Right
Material:
Powdered Metal HSCO Steel
Finish/Coating:
Tin+TiCN
Shank Type:
Endmill Type Shank
Coolant Through:
Yes
