Product Specifications
| # Manufacturer Number | 1547992 |
| Diameter (Inch) | 31/64" |
| Flute Length (mm) | 50.00mm |
| Overall Length (mm) | 102.00mm |
| Drill Point Angle | 135 Degree |
| Number of Flute | 2 |
| Material | Carbide |
| Finish / Coating | REVO-D |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Body Diameter (Inch):
35/64 "
Body Diameter (Decimal Inch):
0.5511";Body Diameter (mm)=14.00mm"
Drill Point Angle:
135 Degree
Material:
Carbide
Finish/Coating:
REVO-D
Overall Length (Inch):
4-1/64 "
Overall Length (Decimal Inch):
4.0157";Overall Length (mm)=102.00mm"
