Product Specifications
| # Manufacturer Number | 1571212 |
| Shank Size (mm) | 6.00mm |
| Flute Length (mm) | 62.00mm |
| Overall Length (mm) | 118.00mm |
| Drill Point Angle | 140 Degree |
| Drill Bit Size (Wire) | #3 |
| Number of Flute | 2 |
| Material | Carbide |
| Finish / Coating | REVO-D |
| Coolant Through | YES |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Letter):
#3
Drill Point Angle:
140 Degree
Flute Length (Inch):
2-4/9";Flute Length (Decimal Inch)=2.4409""
Flute Length (mm):
62.00mm
Overall Length (Inch):
4-2/3";Overall Length (Decimal Inch)=4.6457""
Overall Length (mm):
118.00mm
Material:
Carbide
Finish/Coating:
REVO-D
Flute Type:
Conventional Spiral
Cutting Direction:
Conventional Spiral
Shank Type:
Endmill Type Shank
Coolant Through:
YES
