OSG 1206500 | UNC #4 - 4 Thread Size x 0.141" Shank x 0.319" Length x 1.875" OAL Bottom (1.5P) Chamfer H2 2 Flute BRIGHT Coated HSS 105B Spiral Point Tap

$24.30 $10.94
(You save $13.36)
Brand:
OSG
Thread Size (Decimal Inch):
0.1120"
Class of Fit:
2B, 3B
Thread Limit:
H2
Number of Flutes:
2
Chamfer:
Bottom (1.5P)
Finish/Coating:
Bright
Material:
HSS
Cutting Direction:
Right Hand
interval quantity:
1
SKU:
15028922
UPC:
Weight:
0.01 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 1206500 | UNC #4 - 4 Thread Size x 0.141" Shank x 0.319" Length x 1.875" OAL Bottom (1.5P) Chamfer H2 2 Flute BRIGHT Coated HSS 105B Spiral Point Tap

General Purpose spiral point tap series that provides exceptional value for all general threading applications.

Features & Benefits:

  • HSS material: Increased wear resistance
  • Spiral Point: For through hole applications
  • Bright, Steam Oxide surface treatment: S/O increases mechanical lubricity
  • TiCN coating: Improves wear resistance for extended tap life

Product Specifications
Manufacturer Part Number1206500
Chamfer Length (Decimal Inch)0.038"
Chamfer TypeBottom (1.5P)
Cutting DirectionRight Hand
List NameGENERAL PURPOSE-POT
Major Diameter (Decimal Inch)0.112"
Number of Flutes2
Overall Length (Decimal Inch)1.875"
Shank Diameter (Decimal Inch)0.141"
Square Length (Decimal Inch)0.188"
Square Width (Decimal Inch)0.110"
MaterialHSS
CoatingBright
Tap Drill Size Maximum (Decimal Inch)0.094"
Tap Drill Size Minimum (Decimal Inch)0.085"
Thread Length (Decimal Inch)0.319"
Thread LimitH2
Thread SizeNo. 4
Thread Size (Number)#4
Thread TypeUNC
Thread Per Inch (TPI)40 TPI
Series105B
Product TypeSpiral Point Tap

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
