HY-PRO AL DIN is a premium spiral flute tap for Alloy and Cast Aluminum.
Features & Benefits:
| Manufacturer Part Number | 1301902103 |
| Chamfer Length (Decimal Inch) | 0.125" |
| Major Diameter (Decimal Inch) | 0.500" |
| Neck Length (Decimal Inch) | 1.933" |
| Number of Flutes | 3 |
| Overall Length (Decimal Inch) | 3.937" |
| Shank Diameter (Decimal Inch) | 0.367" |
| Square Length (Decimal Inch) | 0.438" |
| Square Width (Decimal Inch) | 0.275" |
| Maximum Tap Drill Size (Decimal Inch) | 0.457" |
| Minimum Tap Drill Size (Decimal Inch) | 0.446" |
| Thread Length (Decimal Inch) | 0.614" |
| Thread Size (Inch) | 1/2" |
| Coating | Nitride |
| Material | HSSE |
| Helix Direction | Right Hand |
| Helix Angle (Degree) | 50 Degree |
| Series | 13019 Series |
| Product Type | Spiral Flute Tap |
