OSG 1714608 | EXO #2- 56 Thread Size x 0.141" Shank x 0.299" Thread Length x 1.882" OAL UNC STI H2 Plug (5P) Chamfer Type 2 Flute Right Hand V Coated VC-10 314 Spiral Point STI Tap

$73.95 $68.77
(You save $5.18)
Brand:
OSG
Number of Flutes:
2
Overall Length (Decimal Inch):
1.8820"
Shank Diameter (Decimal Inch):
0.1410"
Material:
VC-10
Finish/Coating:
V
Thread Length (Decimal Inch):
0.2990"
Thread Limit:
H2
interval quantity:
1
SKU:
18002422
UPC:
Weight:
0.01 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 1714608 | EXO #2- 56 Thread Size x 0.141" Shank x 0.299" Thread Length x 1.882" OAL UNC STI H2 Plug (5P) Chamfer Type 2 Flute Right Hand V Coated VC-10 314 Spiral Point STI Tap

EXOTAP VC-10 is the premium solution for tapping helicoil (STI) threads in difficult to machine materials.

Features & Benefits:

  • Premium Powdered Metal VC-10 substrate: Increased hardness for longer life
  • Spiral Point: For through hole applications
  • Steam Oxide surface treatment: S/O increases mechanical lubricity
  • OSG V-Coating: Increased hardness, lubricity & wear resistance

Product Specifications
Manufacturer Part Number1714608
Chamfer Length (Decimal Inch)0.089"
Chamfer TypePlug (5P)
Cutting DirectionRight Hand
List NameVC-10 POT STI
Major Diameter (Decimal Inch)0.086"
Neck Length (Decimal Inch)0.610"
Number of Flutes2
Overall Length (Decimal Inch)1.882"
Shank Diameter (Decimal Inch)0.141"
Square Length (Decimal Inch)0.188"
Square Width (Decimal Inch)0.110"
MaterialVC-10
CoatingV
Tap Drill Size Maximum (Decimal Inch)0.096"
Tap Drill Size Minimum (Decimal Inch)0.090"
Thread Length (Decimal Inch)0.299"
Thread LimitH2
Thread SizeNo. 2
Thread Size (Number)#2
Thread TypeUNC STI
Thread Per Inch (TPI)56 TPI
Series314
Product TypeSpiral Point STI Tap

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
