Features & Benefits:
- HSSE material: Increased wear resistance
- Spiral Flute: For blind hole applications
- Steam Oxide surface treatment: S/O increases mechanical lubricity
- OSG V-Coating: Increased hardness, lubricity & wear resistance
Product Specifications
| Manufacturer Part Number | 1732801 |
| Chamfer Length (Decimal Inch) | 0.139" |
| Major Diameter (Decimal Inch) | 0.313" |
| Neck Length (Decimal Inch) | 1.126" |
| Number of Flutes | 3 |
| Overall Length (Decimal Inch) | 2.719" |
| Shank Diameter (Decimal Inch) | 0.318" |
| Square Length (Decimal Inch) | 0.375" |
| Square Width (Decimal Inch) | 0.238" |
| Maximum Tap Drill Size (Decimal Inch) | 0.265" |
| Minimum Tap Drill Size (Decimal Inch) | 0.252" |
| Thread Length (Decimal Inch) | 0.445" |
| Thread Size (Inch) | 5/16" |
| Coating | Steam Oxide |
| Material | HSSE |
| Helix Direction | Right Hand |
| Helix Angle (Degree) | 45 Degree |
| Series | 303 Series |
| Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Brand:
OSG
Thread Size (Inch):
5/16"
Thread Size (Decimal Inch):
0.3125"
Class of Fit:
2B, 3B
Thread Limit:
H3
Number of Flutes:
3
Chamfer:
Modified Bottom (2.5P)
Material:
HSSE
Finish/Coating:
Steam Oxide
Thread Direction:
Right Hand
Threads per Inch (TPI):
18.00
Overall Length (Decimal Inch):
2.7190"
