OSG 17843808 | V-0.844" Diameter x 0.875" Shank x 155.000" Flute Length x 223.00mm OAL x 130 Degree Point Angle 2 Flute V Coated HSS-CO 1700 Jobber Length Drill Bit

$629.76 $598.27
(You save $31.49)
Brand:
OSG
Coolant Through:
Yes
Cutting Direction:
Right Hand
Material:
HSS-CO
Finish/Coating:
V
interval quantity:
1
SKU:
10290857
UPC:
Weight:
0.87 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping
OSG 17843808 | V-0.844" Diameter x 0.875" Shank x 155.000" Flute Length x 223.00mm OAL x 130 Degree Point Angle 2 Flute V Coated HSS-CO 1700 Jobber Length Drill Bit

V-HO-GDR OIL HOLE Drills Designed for a Wide Range of Materials, Coolant Thru.


Product Specifications
Manufacturer Part Number17843808
Coolant ThroughYes
Cutting Diameter Tolerance (Decimal Inch)+0 / -0.0013"
Cutting Diameter Tolerance (mm)+0 / -0.033mm
Cutting Diameter Tolerance Specificationh8
Cutting DirectionRight Hand
Diameter (Inch)27/32"
Diameter (Decimal Inch)0.844"
Diameter (mm)21.43mm
Flute Length (mm)155.00mm
Helix Angle (Degree)30 Degree
Helix DirectionRight Hand
List NameV-HO-GDR
Number of Flutes2
Overall Length (mm)223.00mm
Point Angle (Degree)130 Degree
Shank Diameter (Decimal Inch)0.875"
MaterialHSS-CO
CoatingV
Series1700
Product TypeJobber Length Drill Bit

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
