OSG 1971101 | M M6.00x1.00mm Thread Size x 6.48mm Shank x 15.90mm Length x 63.50mm OAL Bottom (1.5P) Chamfer D5 4 Flute Steam Oxide Coated HSS 141 Straight Flute Tap

OSG 1971101 | M M6.00x1.00mm Thread Size x 6.48mm Shank x 15.90mm Length x 63.50mm OAL Bottom (1.5P) Chamfer D5 4 Flute Steam Oxide Coated HSS 141 Straight Flute Tap

SKU: 18002981 Weight: 0.03 LBS Minimum Purchase: 1 unit
UPC:
$20.03 $9.01
(You save $11.02)
Shipping: Calculated at Checkout

About This Item

General Purpose straight flute tap series that provides exceptional value for all general threading applications.

Features & Benefits:

  • HSS material: Increased wear resistance
  • Straight Flute: For blind and through hole applications
  • Bright, Steam Oxide surface treatment: S/O increases mechanical lubricity
  • TiN, TiCN surface treatments: Improves wear resistance for extended tap life

Product Specifications
Manufacturer Part Number1971101
Chamfer Length (Decimal Inch)0.059"
Chamfer TypeBottom (1.5P)
Cutting DirectionRight Hand
List NameGENERAL PURPOSE-HT
Major Diameter (mm)6.00mm
Neck Length (mm)30.00mm
Number of Flutes4
Overall Length (mm)63.50mm
Pitch (mm)1.00mm
Shank Diameter (mm)6.48mm
Square Length (mm)7.94mm
Square Width (mm)4.85mm
MaterialHSS
CoatingSteam Oxide
Tap Drill Size Maximum (mm)5.15mm
Tap Drill Size Minimum (mm)4.92mm
Thread Length (mm)15.90mm
Thread LimitD5
Thread SizeM6
Thread TypeM
Series141
Product TypeStraight Flute Tap
