OSG 2890600 | HY-PRO M4 x 0.70mm Thread Size x 4.27mm Shank x 8.30mm Thread Length M D4 Plug (4P) Chamfer Type 3 Flute Right Hand Bright Coated HSSE 289 Spiral Point Tap

$29.05 $17.72
(You save $11.33)
Brand:
OSG
Cutting Direction:
Right Hand
Number of Flutes:
3
Material:
HSSE
Finish/Coating:
Bright
Thread Limit:
D4
interval quantity:
1
SKU:
18003918
UPC:
Weight:
0.01 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 2890600 | HY-PRO M4 x 0.70mm Thread Size x 4.27mm Shank x 8.30mm Thread Length M D4 Plug (4P) Chamfer Type 3 Flute Right Hand Bright Coated HSSE 289 Spiral Point Tap

HY-PRO DIN is the original "Do it All" premium spiral point tap for a wide range of materials.

Features & Benefits:

  • HSSE material: Increased wear resistance
  • Spiral Point: For through hole applications
  • Bright, Steam Oxide surface treatment: S/O increases mechanical lubricity
  • TiCN coating: Improves wear resistance for extended tap life

Product Specifications
Manufacturer Part Number2890600
Chamfer Length (Decimal Inch)0.110"
Chamfer TypePlug (4P)
Cutting DirectionRight Hand
List NamePOT
Major Diameter (mm)4.00mm
Neck Length (mm)19.00mm
Number of Flutes3
Overall Length (mm)54.00mm
Pitch (mm)0.70mm
Shank Diameter (mm)4.27mm
Square Length (mm)6.35mm
Square Width (mm)3.33mm
MaterialHSSE
CoatingBright
Tap Drill Size Maximum (mm)3.42mm
Tap Drill Size Minimum (mm)3.24mm
Thread Length (mm)8.30mm
Thread LimitD4
Thread SizeM4
Thread TypeM
Series289
Product TypeSpiral Point Tap

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
