Standard Carbide End Mills for General Milling Applications
Features & Benefits:
- Economical 4-corner insert with a chipbreaker that enhances cutting performance while maintaining rigidity: Ideally configured for rough milling
- High feed design reduces radial cutting forces and tool vibration: Highly efficient machining, even with long overhangs
- Small cutting angle reduces actual chip thickness: Capable of increased feed rates and high metal removal rates
- End mill and face mill styles, Inch and Metric: Complete Offering
Product Specifications
| Manufacturer Part Number | 484-125011 |
| Cutting Diameter Tolerance (Decimal Inch) | +0 / -0.002" |
| Cutting Direction | Right Hand |
| Diameter (Inch) | 1/8" |
| Diameter (Decimal Inch) | 0.125" |
| Helix Angle (Degree) | 30 Degree |
| Helix Direction | Right Hand |
| Length of Cut (Decimal Inch) | 1.000" |
| List Name | STANDARD CARBIDE SQ |
| Number of Flutes | 4 |
| Overall Length (Decimal Inch) | 3.000" |
| Shank Diameter (Decimal Inch) | 0.125" |
| Material | Carbide |
| Coating | TiAlN |
| Series | 484 |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
OSG
Cutting Direction:
Right Hand
Helix Angle:
30 Degree
Length of Cut (Decimal Inch):
1.0000"
Number of Flutes:
4
Overall Length (Decimal Inch):
3.0000"
Material:
Carbide
Finish/Coating:
TiAlN
