High Performance Diamond Coated End Mills for Graphite & Non-Ferrous Materials.
| Manufacturer Part Number | 70410716 |
| Cutting Diameter Tolerance (Decimal Inch) | +0 / -0.002" |
| Cutting Direction | Right Hand |
| Diameter (Inch) | 1/8" |
| Diameter (Decimal Inch) | 0.125" |
| Helix Angle (Degree) | 30 Degree |
| Helix Direction | Right Hand |
| Length of Cut (Decimal Inch) | 1.000" |
| List Name | DIAMOND D-GF-EML |
| Number of Flutes | 4 |
| Overall Length (Decimal Inch) | 3.000" |
| Shank Diameter (Decimal Inch) | 0.125" |
| Shank Tolerance | h6 |
| Material | Carbide |
| Coating | DIAMOND |
| Series | 7041 |
| Product Type | Square End Mill |
