Features:
- Made-in-USA quality
- Repeatable accuracy of 3 microns at 3X diameter
- Simplicity-no expensive setup machines required
- DIN-B flange coolant enabled
- Balanced to 25,000 RPM @ G2.5
Product Specifications
| Taper | BT40 |
| Collet Series | ER16 |
| Body Diameter (Inch) | 1.75" |
| Shank Size (Inch) | 2.48" |
| Shank Length (Inch) | 2.57" |
| Overall Length (Inch) | 7.29" |
| Projection (Inch) | 4.72" |
| Nose Diameter (Inch) | 1.18" |
