Copy face mill with double negative geometry which utilises 5 off RCMT 10T3MO.. single-sided inserts, cutting diameter 1.500'' with M16 threaded shank for standard modular tool-holders, 1.654'' protrusion length, through coolant for face milling, copy milling, ramping, helical milling and plunge milling with a maximum depth of cut of .197''.
Product Specifications
| EDP Number | 7455367 |
| Peripheral Effective Cutting Edge Count | 5 |
| Coolant Supply Property | 1 |
| Axial Rake Angle | -7 |
| Radial Rake Angle | -2.1 |
| Max Rotational Speed | 16500 |
| Connection Diameter (mm) | 17 mm |
| Connection Diameter (Inch) | 0.669" |
| Hub Diameter (Inch) | 1.142" |
| Cutting Diameter (mm) | 28.1 mm |
| Cutting Diameter (Inch) | 1.106" |
| Max Cutting Diameter (Inch) | 1.5" |
| Overall Length (mm) | |
| Overall Length (Inch) | |
| Functional Length (Inch) | 1.654" |
| Thread Diameter Size | M16 |
