Single-sided milling insert OFKR 0704 with chip-breakers, octagonal for a maximum depth of cut of 12.0 mm, with an indexing accuracy according to ISO-tolerance class-K and M geometry, M8330 PVD coated fine grained WC-Co carbide within ISO-grade range P20-P40 for machining of steel.
Product Specifications
| EDP Number | 7447924 |
| Maximum Depth of Cut (mm) | 12 mm |
| Max Depth of Cut (Inch) | 0.472" |
| Coating Property | 1 |
| Fixing Hole Diameter (mm) | 2.65 mm |
| Fixing Hole Diameter (Inch) | 0.104" |
| Inscribed Circle Diameter (mm) | 17.845 mm |
| Inscribed Circle Diameter (Inch) | 0.703" |
| Insert Thickness (mm) | 4.56 mm |
| Insert Thickness (Inch) | 0.18" |
| Coating Process | PVD |
| Coating | M8330 |
| Surface Color | Gold |
| Min Depth of Cut (mm) | 0.5 mm |
| Min Depth of Cut (Inch) | 0.02" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Ships:
From Partner Facility
interval quantity:
10
