Pramet PSR3-R14:S45 | 0.866" Circle Diameter x 10 mm Thickness Turning Insert

$35.05 $21.65
(You save $13.40)
Ships:
From Partner Facility
Ships:
From Partner Facility
Brand:
Pramet
Inscribed Circle (Inch):
55/64"
Inscribed Circle (Decimal Inch):
0.8660"
Inscribed Circle (mm):
22mm
Thickness (Inch):
25/64"
Thickness (Decimal Inch):
0.3940"
Thickness (mm):
10mm
interval quantity:
10
SKU:
23152083
UPC:
Weight:
0.05 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout
Scarfing ring with an outside diameter of 22 mm, an inside diameter of 12 mm, 10 mm thick and a working radius of 13.7 mm for tube diameters from 32 to 41 mm, S45 uncoated WC-(Ti, Ta, Nb)C-Co carbide within ISO-grade ranges P30-P50 and M30-M40 for deburring the inside of steel and stainless-steel tubes and pipes.

Product Specifications
EDP Number6753035
Profile Radius (mm)13.7 mm
Inscribed Circle Diameter (mm)22 mm
Inscribed Circle Diameter (Inch)0.866"
Insert Diameter (mm)22 mm
Insert Cutting Diameter (mm)12 mm
Insert Thickness (mm)10 mm
CoatingS45
Surface ColorSilver
Insert Cutting Diameter (Inch)0.472"
Chipbreaker Manufacturer's DesignationNo chipbreaker
Country of originCzech Republic
