Screw clamp turning tool for holding a 80 Degree rhombus positive insert with an inscribed circle diameter of 1/2'', 3/16'' thick (ANSI designation CC.. 43. ), left hand 95 Degree side and end cutting with off-set shank, 1'' tool height x 1'' width x 6'' long for chamfering, taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder.
Product Specifications
| EDP Number | 6788655 |
| Functional Height (Inch) | 1" |
| Functional Width (Inch) | 1.25" |
| Maximum Axial Groove Outside Diameter (mm) | |
| Shank Height (Inch) | 1" |
| Shank Width (Inch) | |
| Functional Length (Inch) | 6" |
| Head Length (Inch) | 0.83" |
| Country of origin | Czech Republic |
