Single-sided milling insert XPHT 1604 with chip-breakers, 80 Degree rhomboid for a maximum depth of cut of 15.0 mm, with 1.2 mm corner radius, an indexing accuracy according to ISO-tolerance class-H with rounded cutting edges and facet, 8215 PVD coated fine grained WC-Co carbide for machining with chamfer mills J(T)-SXP16.
Product Specifications
| EDP Number | 6753427 |
| Maximum Depth of Cut (mm) | 15 mm |
| Max Depth of Cut (Inch) | 0.591" |
| Coating Property | 1 |
| Fixing Hole Diameter (mm) | 4.4 mm |
| Fixing Hole Diameter (Inch) | 0.173" |
| Cutting Edge Length (mm) | 15.88 mm |
| Cutting Edge Length (Inch) | 0.625" |
| Insert Width (mm) | 9.525 mm |
| Insert Width (Inch) | 0.375" |
| Insert Thickness (mm) | 4.76 mm |
| Insert Thickness (Inch) | 0.187" |
| Corner Radius (mm) | 1.2 mm |
| Corner Radius (Inch) | 0.047" |
| Coating Process | PVD |
| Coating | 8215 |
| Surface Color | Purple - Black |
| Min Depth of Cut (mm) | 1.2 mm |
| Min Depth of Cut (Inch) | 0.047" |
| Country of origin | Czech Republic |
