Features:
- Balanced to 25000 RPM
- 0.0001" TIR
- Includes Hi-Q Nut
- High Vibration Damping
Product Specifications
| Manufacturer Part Number | 4150.11650 |
| Projection (Decimal Inch) | 3.940" |
| Projection (mm) | 100.00mm |
| Nose Diameter (Decimal Inch) | 1.103" |
| Nose Diameter (mm) | 28.00mm |
| TIR (Decimal Inch) | 0.0001" |
| TIR (mm) | 0.003mm |
| Maximum | 25000 RPM |
| Length (Decimal Inch) | 3.0000" |
| Width (Decimal Inch) | 3.0000" |
| Height (Decimal Inch) | 12.0000" |
| Coolant Thru Capable | Yes |
| Product Type | Collet Chuck |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Rego-Fix
Length (Inch):
3"
Length (Decimal Inch):
3.0000"
Length (mm):
76.20mm
Width (Inch):
3"
Width (Decimal Inch):
3.0000"
Width (mm):
76.20mm
Height (Inch):
12"
Height (Decimal Inch):
12.0000"
Height (mm):
304.80mm
Projection (Inch):
3-47/50"
Projection (Decimal Inch):
3.9400"
Projection (mm):
100.00mm
Nose Diameter (Inch):
1-7/68"
Nose Diameter (Decimal Inch):
1.1030"
Nose Diameter (mm):
28.00mm
TIR (Decimal Inch):
0.0001"
TIR (mm):
0.003mm
Maximum (RPM):
25000 RPM
Coolant Thru Capable:
Yes
