The ultimate live center for grinding is provided by Riten's unique design. Ideal for precision grinding applications; ยฑ 0.00004.
<| # MFG | 12209 |
| Taper | 9 Jarno |
| Accuracy | ยฑ 0.00004 |
| Point Length (Inch) | 1.000" |
| Max Workpiece Weight (lbs) | 1000 lbs. |
| Head Length (Inch) | 0.938" |
| Head Diameter (Inch) | 1.688" |
| Max RPM | 1000 |
| Point Diameter (Inch) | 0.875" |
| Gage Line to Back of Head (Inch) | 0.188" |
| Point Style | Standard Point |
| Series | Super Accurate Live Centers |
