Features:
- Accuracy guaranteed to ± 0.00005
- Through-hardened to 61-63 Rc
- Works on all CNC machines
- Meets the rigid requirements of CNC turning
- All stock items
- Riten full service and repair
Product Specifications
| # MFG | 68913 |
| Taper | 3 Morse |
| Accuracy | ± 0.00005 |
| Point Length (Inch) | 1.625" |
| Gage Line to Point (Inch) | 2.375" |
| Point Diameter (Inch) | 1.000" |
| Threads | 1-1/8-12" |
| Carbide Tip Diameter (Inch) | 0.750" |
| Point Style | Standard (Carbide Tipped) |
| Series | CNC Dead Centers |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Riten
Length (Inch):
1"
Length (Decimal Inch):
1.6250"
Length (mm):
41.28mm
Diameter (Inch):
1"
Diameter (Decimal Inch):
1.0000"
Diameter (mm):
25.40mm
