Features:
| # MFG | 17216 |
| Type | Type V Standard Center |
| Taper | 16 Jarno |
| Accuracy | ± 0.0001 |
| Overall Length (Inch) | 8.020" |
| Point Length (Inch) | 2.000" |
| Gage Line to Point (Inch) | 2.880" |
| Max Thrust Load (lbs) | 1088 lbs. |
| Max Spring Travel (Inch) | 0.188" |
| Max Workpiece Weight (lbs) | 1450 lbs. |
| Max RPM | 1500 |
| Point Diameter (Inch) | 1.075" |
| Series | Concentric Spring Loaded Live Centers |
