Features:
- Accuracy guaranteed to ± 0.0001.
- For heavy, large center hole workpieces
- Interchangeable pipe point for greater precision in difficult configurations, applications, and tool clearances
- High RPM capacity
Product Specifications
| # MFG | 56203 |
| Taper | 3 Morse |
| Accuracy | ± 0.0001 |
| Gage Line to Point (Inch) | 3.250" |
| Max Workpiece Weight (lbs) | 1350 lbs. |
| Max RPM | 8500 |
| Point Diameter (Inch) | 2.500" |
| Minimum Diameter (Inch) | 0.563" |
| Gage Line to Back of Head (Inch) | 0.375" |
| Nose Style | Bull Nose |
| Series | Precision Bull Nose Live Centers |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Riten
Diameter (Inch):
2-1/2"
Diameter (Decimal Inch):
2.5000"
Diameter (mm):
63.50mm
