Product Specifications
# Manufacturer Number | MB-203-06 |
Cutting Diameter (mm) | 6.00mm |
Shank Diameter (mm) | 6.00mm |
Maximum Cutting Diameter (mm) | 0.24mm |
Flute Length (mm) | 14.00mm |
Overall Length (mm) | 57.00mm |
Helix Angle (Degree) | 30 Degree |
Helix Direction (Hand) | Right Hand |
Cutting Direction (Hand) | Right Hand |
Coating | Uncoated |
Product Type | Ball End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
RobbJack
Number of Flutes:
2
Overall Length (Inch):
2-1/4"
Overall Length (Decimal Inch):
2.2400"
Overall Length (mm):
57.00mm
Shank Diameter (Inch):
15/64"
Shank Diameter (Decimal Inch):
0.2362"
Shank Diameter (mm):
6.00mm
Finish/Coating:
Uncoated
Cutting Direction:
Right Hand
Helix Angle (Degree):
30 Degree
