Product Specifications
| # Manufacturer Number | MNS-402-08-FL |
| Cutting Diameter (mm) | 8.00mm |
| Shank Diameter (mm) | 8.00mm |
| Maximum Cutting Diameter (mm) | 0.32mm |
| Flute Length (mm) | 16.00mm |
| Overall Length (mm) | 64.00mm |
| Corner Chamfer (mm) | 0.30mm |
| Corner Chamfer (Degree) | 45 Degree |
| Helix Direction (Hand) | Right Hand |
| Cutting Direction (Hand) | Right Hand |
| Coating | AlTiN Coated |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
RobbJack
Number of Flutes:
4
Finish/Coating:
AlTiN
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3149"
Shank Diameter (mm):
8.00mm
Overall Length (Inch):
2-33/64"
Overall Length (Decimal Inch):
2.5200"
Overall Length (mm):
64.00mm
Cutting Direction:
Right Hand
Mill Diameter (Inch):
5/16"
Mill Diameter (Decimal Inch):
0.3149"
Mill Diameter (mm):
8.00mm
