| Manufacturer Part Number | SB-201-10-T |
| Cutting Diameter (Decimal Inch) | 0.313" |
| Shank Diameter (Decimal Inch) | 0.313" |
| Maximum Cutting of Diameter (Decimal Inch) | 0.313" |
| Overall Length (Decimal Inch) | 2.500" |
| Flute Length (Decimal Inch) | 0.438" |
| Corner Radius (Decimal Inch) | 0.156" |
| Number of Flutes | 2 |
| Helix Angle (Degree) | 30 Degree |
| Cutting Direction | Right Hand |
| Helix Direction | Right Hand |
| Series | SB-201 |
| Coating | TiN |
| Product Type | Ball End Mill |
