Product Specifications
| Manufacturer Part Number | XG-402-20-BN |
| Cutting Diameter (Decimal Inch) | 0.625" |
| Shank Diameter (Decimal Inch) | 0.625" |
| Maximum Cutting of Diameter (Decimal Inch) | 0.624" |
| Overall Length (Decimal Inch) | 3.500" |
| Flute Length (Decimal Inch) | 1.250" |
| Corner Radius (Decimal Inch) | 0.313" |
| Number of Flutes | 4 |
| Cutting Direction | Right Hand |
| Helix Direction | Right Hand |
| Series | XG-402-BN |
| Coating | AlTiN |
| Product Type | Ball End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
RobbJack
Mill Diameter (Inch):
5/8"
Mill Diameter (Decimal Inch):
0.6250"
Mill Diameter (mm):
15.88mm
Number of Flutes:
4
Overall Length (Inch):
3-1/2"
Overall Length (Decimal Inch):
3.5000"
Overall Length (mm):
88.90mm
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6250"
Shank Diameter (mm):
15.88mm
Finish/Coating:
AlTiN
Cutting Direction:
Right Hand
