Product Specifications
| Manufacturer Part Number | B120350RC |
| Minimum Bore Diameter (Decimal Inch) | 0.120" |
| Maximum Bore Diameter (Decimal Inch) | 0.350" |
| Maximum Bore Depth (Decimal Inch) | 0.350" |
| Corner Radius (Decimal Inch) | 0.005-0.008" |
| Shank Diameter (Decimal Inch) | 0.187" |
| Overall Length (Decimal Inch) | 2.000" |
| Material | Solid Carbide |
| Coating | TiN |
| Product Type | Boring Bar |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Minimum Bore Diameter (Inch):
1/8"
Minimum Bore Diameter (Decimal Inch):
0.1200"
Minimum Bore Diameter (mm):
3.05mm
Material:
Solid Carbide
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1870"
Shank Diameter (mm):
4.75mm
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Finish/Coating:
TiN
interval quantity:
1
