Seco Tools 00023235 | 905L006 0.60mm Diameter x 3.00mm Shank x 0.05mm Corner Radius x 40.00mm OAL x 20 Degree Helix Angle 2 Flute MEGA Coated Carbide Corner Radius End Mill

$142.00 $133.48
(You save $8.52)
Brand:
Seco Tools
Shank Type:
Cylindrical
Material:
Carbide
Finish/Coating:
MEGA
Overall Length (Inch):
40"
Overall Length (Decimal Inch):
1.5748"
Overall Length (mm):
40.00mm
Cutting Direction:
Right Hand
interval quantity:
1
SKU:
25268513
UPC:
Weight:
0.01 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 00023235 | 905L006 0.60mm Diameter x 3.00mm Shank x 0.05mm Corner Radius x 40.00mm OAL x 20 Degree Helix Angle 2 Flute MEGA Coated Carbide Corner Radius End Mill

Product Specifications
Manufacturer Part Number00023235
Cutting Diameter (mm)0.60mm
Cutting Diameter 1 (mm)0.60mm
Connection Diameter Machine Side (mm)3.00mm
Shank Diameter (mm)3.00mm
Neck Diameter (mm)0.55mm
Minimum Helical Interpolation Hole Diameter (mm)0.78mm
Maximum Helical Interpolation Hole Diameter (mm)1.10mm
Cutting Edge Effective Length (mm)0.90mm
Neck Length (mm)3.00mm
Neck Length 1 (mm)3.00mm
Neck Length 2 (mm)7.70mm
Minimum Clamping Length (mm)28.00mm
Length Variant Cataloque3
Theoretical Cutting Edge Length (mm)0.90mm
Overall Length (mm)40.00mm
Number of Flute2
Pheripheral Cutting Edge Count2
Maximum Depth of Cut (mm)0.90mm
Corner Radius (mm)0.05mm
Axial Runout (mm)0.01mm
Radial Runout (mm)0.01mm
Cutting Edge Count2
Face Cutting Edge Count2
Tool Cutting Edge Angle (Degree)90 Degree
Tool Cutting Edge Angle In Feed Direction End (Degree)92.5 Degree
Tool Cutting Edge Angle In Feed Direction Side (Degree)90 Degree
Collision Angle (Degree)9 Degree
Flute Helix Angle (Degree)20 Degree
Rake Radial Angle (Degree)4 Degree
Cutting DirectionRight Hand
Flute Helix HandRight Hand
Center Cutting CapabilityYes
Cutting Geometry TypeJM905
Cutting Geometry Type TechnicalJM905
Internal Coolant ChannelNo
Cutting Item Material TypeCarbide
Shank TypeCylindrical
MaterialCarbide
CoatingMEGA-T
Product TypeCorner Radius End Mill
