Product Specifications
| Manufacturer Part Number | 00094373 |
| Body Diameter (Decimal Inch) | 0.630" |
| Body Diameter (mm) | 16.00mm |
| Minimum Cutting Diameter Internal (Decimal Inch) | 1.575" |
| Minimum Cutting Diameter Internal (mm) | 40.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.969" |
| Contact Surface Diameter Machine Side (mm) | 50.00mm |
| Functional Length (Decimal Inch) | 2.756" |
| Functional Length (mm) | 70.00mm |
| Head Length (Decimal Inch) | 1.811" |
| Head Length (mm) | 46.00mm |
| Usable Length (Decimal Inch) | 1.811" |
| Usable Length (mm) | 46.00mm |
| Functional Width (Decimal Inch) | 0.433" |
| Functional Width (mm) | 11.00mm |
| Coolant Supply Property | 1 |
| Cutting Direction | Right Hand |
| Insert Clamping System | S |
| Tool Cutting Edge Angle (Degree) | 91 Degree |
| Tool Cutting Edge Angle Code | F |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 91 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 118.94 Degree |
| Inclination Angle (Degree) | -4 Degree |
| Insert Shape Code | T |
| Shank Type | Seco-Capto |
| Product Type | Modular Turning Head |
