Product Specifications
| Manufacturer Part Number | 02427371 |
| Cutting Diameter (mm) | 10.00mm |
| Connection Diameter Machine Side (mm) | 20.00mm |
| Maximum Cutting Diameter (mm) | 16.00mm |
| Shank Diameter (mm) | 20.00mm |
| Maximum Helical Interpolation Hole Diameter (mm) | 30.00mm |
| Minimum Helical Interpolation Hole Diameter (mm) | 26.00mm |
| Protruding Length (mm) | 70.00mm |
| Shank Length (mm) | 60.00mm |
| Overall Length (mm) | 130.00mm |
| Maximum Depth of Cut (mm) | 3.00mm |
| Cutting Pitch Density | Normal |
| Rake Radial Angle (Degree) | 0.6 Degree |
| Rake Radial Angle (Degree) | 0.6 Degree |
| Rake Orthogonal Angle (Degree) | 0.6 Degree |
| Maximum Ramping Angle (Degree) | 15.62 Degree |
| Maximum Rotational Speed (rpm) | 28800 rpm |
| Insert Shape Code | R |
| Shank Type | Cylindrical |
| Product Type | Copy Mill Round Insert |
