Seco Tools 02826812 | JHP993080D2C.0Z4 8.00mm Diameter x 8.00mm Shank x 60.00mm OAL x 38 Degree Helix Angle 4 Cutting Edge SIRON Coated Carbide Corner Chamfer End Mill

$139.00 $130.66
(You save $8.34)
Brand:
Seco Tools
Shank Type:
Cylindrical
Material:
Carbide
Finish/Coating:
SIRON
Overall Length (Inch):
60"
Overall Length (Decimal Inch):
2.3622"
Overall Length (mm):
60.00mm
Cutting Direction:
Right Hand
interval quantity:
1
SKU:
25270460
UPC:
Weight:
0.08 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 02826812 | JHP993080D2C.0Z4 8.00mm Diameter x 8.00mm Shank x 60.00mm OAL x 38 Degree Helix Angle 4 Cutting Edge SIRON Coated Carbide Corner Chamfer End Mill

Product Specifications
Manufacturer Part Number02826812
Cutting Diameter (mm)8.00mm
Cutting Diameter 1 (mm)8.00mm
Connection Diameter Machine Side (mm)8.00mm
Shank Diameter (mm)8.00mm
Minimum Helical Interpolation Hole Diameter (mm)10.40mm
Maximum Helical Interpolation Hole Diameter (mm)15.58mm
Cutting Edge Effective Length (mm)18.00mm
Minimum Clamping Length (mm)36.00mm
Length Variant Cataloque2
Theoretical Cutting Edge Length (mm)18.00mm
Overall Length (mm)60.00mm
Corner Chamfer Width (mm)0.20mm
Corner Chamfer Width Lower Tolerance (mm)0.05
Number of Flute4
Pheripheral Cutting Edge Count4
Maximum Depth of Cut (mm)18.00mm
Axial Runout (mm)0.02mm
Radial Runout (mm)0.02mm
Cutting Edge Count4
Face Cutting Edge Count4
Tool Cutting Edge Angle (Degree)90 Degree
Tool Cutting Edge Angle In Feed Direction End (Degree)92 Degree
Tool Cutting Edge Angle In Feed Direction Side (Degree)90 Degree
Corner Chamfer Angle (Degree)45 Degree
Flute Helix Angle (Degree)38 Degree
Rake Radial Angle (Degree)7 Degree
Maximum Ramping Angle (Degree)10 Degree
Cutting DirectionRight Hand
Flute Helix HandRight Hand
Center Cutting CapabilityYes
Cutting Geometry TypeJHP993
Cutting Geometry Type TechnicalJHP993
Internal Coolant ChannelNo
Cutting Item Material TypeCarbide
Shank TypeCylindrical
MaterialCarbide
CoatingSIRON-A
Product TypeCorner Chamfer End Mill
