Seco Tools 02965427 |218.20-150ER-ME07 0.469" Inscribed Circle Diameter x 0.591" Corner Radius x 0.236" Thickness 2 Cutting Edge Carbide Milling Insert

$57.29
Brand:
Seco Tools
Material:
Carbide
Width (Inch):
15/32"
Width (Decimal Inch):
0.4689"
Width (mm):
11.91mm
Length (Inch):
1-10/77"
Length (Decimal Inch):
1.1299"
Length (mm):
28.70mm
Inscribed Circle (Inch):
15/32"
Inscribed Circle (Decimal Inch):
0.4689"
Inscribed Circle (mm):
11.91mm
Thickness (Inch):
4/17"
Thickness (Decimal Inch):
0.2358"
Thickness (mm):
5.99mm
interval quantity:
1
SKU:
23283677
UPC:
Weight:
0.03 LBS
Shipping:
Calculated at Checkout
Seco Tools 02965427 |218.20-150ER-ME07 0.469" Inscribed Circle Diameter x 0.591" Corner Radius x 0.236" Thickness 2 Cutting Edge Carbide Milling Insert

Product Specifications
Manufacturer Part Number02965427
Fixing Hole Diameter (Decimal Inch)0.177"
Fixing Hole Diameter (mm)4.50mm
Inscribed Circle Diameter (Decimal Inch)0.469"
Inscribed Circle Diameter (mm)11.91mm
Insert Length (Decimal Inch)1.130"
Insert Length (mm)28.70mm
Corner Radius (Decimal Inch)0.591"
Corner Radius (mm)15.00mm
Insert Thickness (Decimal Inch)0.236"
Insert Thickness (mm)5.99mm
Cutting Edge Count2
Clearance Angle Major (Degree)15 Degree
Insert Rake Angle (Degree)6 Degree
Insert HandRight Hand
Cutting Geometry TypeME
Cutting Geometry Type TechnicalME07
Pocket Seat Code of The Cutter218.20-150
Insert Size And Shape218.20-150
Insert Shape Code218.20
MaterialCarbide
Product TypeMilling Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Seco Tools
Material:
Carbide
Width (Inch):
15/32"
Width (Decimal Inch):
0.4689"
Width (mm):
11.91mm
Length (Inch):
1-10/77"
Length (Decimal Inch):
1.1299"
Length (mm):
28.70mm
Inscribed Circle (Inch):
15/32"
Inscribed Circle (Decimal Inch):
0.4689"
Inscribed Circle (mm):
11.91mm
Thickness (Inch):
4/17"
Thickness (Decimal Inch):
0.2358"
Thickness (mm):
5.99mm
interval quantity:
1
