Product Specifications
| Manufacturer Part Number | 03212902 |
| Cutting Diameter (Decimal Inch) | 0.744" |
| Cutting Diameter (mm) | 18.90mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.181" |
| Contact Surface Diameter Machine Side (mm) | 30.00mm |
| Maximum Cutting Diameter (Decimal Inch) | 1.250" |
| Maximum Cutting Diameter (mm) | 31.75mm |
| Thread Diameter Size | M16 |
| Maximum Helical Interpolation Hole Diameter (Decimal Inch) | 2.421" |
| Maximum Helical Interpolation Hole Diameter (mm) | 61.50mm |
| Minimum Helical Interpolation Hole Diameter (Decimal Inch) | 1.994" |
| Minimum Helical Interpolation Hole Diameter (mm) | 50.65mm |
| Functional Length (Decimal Inch) | 1.378" |
| Functional Length (mm) | 35.00mm |
| Overall Length (Decimal Inch) | 2.274" |
| Overall Length (mm) | 57.75mm |
| Maximum Depth of Cut (mm) | 1.87mm |
| Maximum Depth of Cut (Decimal Inch) | 0.074" |
| Connection Mounting Torque (Nm) | 80.0 Nm |
| Programming Radius (Decimal Inch) | 0.137" |
| Programming Radius (mm) | 3.47mm |
| Uncut Thickness (Decimal Inch) | 0.0276 |
| Uncut Thickness (mm) | 0.7 |
| Coolant Entry Style Code | 1 |
| Cutting Pitch Density | Close |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 3 |
| Rake Radial Angle (Degree) | -8 Degree |
| Rake Radial Angle (Degree) | -8 Degree |
| Rake Orthogonal Angle (Degree) | -8 Degree |
| Axial Rake Angle (Degree) | 2 Degree |
| Maximum Ramping Angle (Degree) | 4.9 Degree |
| Maximum Rotational Speed (rpm) | 31100 rpm |
| Insert Shape Code | L |
| Shank Type | Combimaster |
| Product Type | Indexable High-Feed End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Cutting Diameter (Inch):
32/43"
Cutting Diameter (Decimal Inch):
0.7441"
Cutting Diameter (mm):
18.90mm
Maximum Depth of Cut (Inch):
5/68"
Maximum Depth of Cut (Decimal Inch):
0.0736"
Maximum Depth of Cut (mm):
1.87mm
Shank Type:
Combimaster
interval quantity:
1
