| Manufacturer Part Number | 10139632 |
| Thread Diameter (Decimal Inch) | 0.875" |
| Thread Diameter (mm) | 22.23mm |
| Threading Chamfer Length (Decimal Inch) | 0.203" |
| Threading Chamfer Length (mm) | 5.15mm |
| Tap Chamfer Length (Decimal Inch) | 0.203" |
| Tap Chamfer Length (mm) | 5.15mm |
| Connection Diameter Machine Side (Decimal Inch) | 0.709" |
| Connection Diameter Machine Side (mm) | 18.00mm |
| Shank Diameter (Decimal Inch) | 0.709" |
| Shank Diameter (mm) | 18.00mm |
| Functional Length (Decimal Inch) | 4.719" |
| Functional Length (mm) | 119.85mm |
| Usable Length (Decimal Inch) | 3.071" |
| Usable Length (mm) | 78.00mm |
| Overall Length (Decimal Inch) | 4.921" |
| Overall Length (mm) | 125.00mm |
| Thread Length (Decimal Inch) | 0.669" |
| Thread Length (mm) | 17.00mm |
| Thread Diameter Size | UNF7/8-14 |
| Recommended Premachined Hole Diameter (Decimal Inch) | 0.807" |
| Recommended Premachined Hole Diameter (mm) | 20.50mm |
| Connection Size Code | 18.00X14.50 |
| Connection Size Code Machine Side | 18.00X14.50 |
| Maximum Premachined Hole Diameter (Decimal Inch) | 0.814" |
| Maximum Premachined Hole Diameter (mm) | 20.68mm |
| Minimum Threads Per Inch (mm) | 14.00mm |
| Maximum Threads Per Inch (mm) | 14.00mm |
| Flute Helix Angle (Degree) | 40 Degree |
| Number of Flute | 4 |
| Shank Type | Cylindrical |
| Thread Tolerance Class | 2B |
| Threading Chamfer Type | C |
| Thread Form Type | UNF |
| Cutting Direction | Right Hand |
| Cutting Geometry Type | T32 |
| Cutting Geometry Type Technical | Spiral |
| Material | HSS-E |
| Coating | TiAIN+TiN |
| Product Type | Spiral Flute Tap |
