Product Specifications
| Manufacturer Part Number | 10171114 |
| Cutting Diameter (mm) | 3.15mm |
| Connection Diameter Machine Side (mm) | 6.00mm |
| Shank Diameter (mm) | 6.00mm |
| Shank Length (mm) | 36.00mm |
| Usable Length (mm) | 23.00mm |
| Overall Length (mm) | 66.00mm |
| Point Length (mm) | 0.57mm |
| Corner Chamfer Width (mm) | 0.15mm |
| Shank Type | Cylindrical |
| Coolant Entry Style Code | 4 |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 4 |
| Flute Helix Angle (Degree) | 30 Degree |
| Flute Helix Direction | Right |
| Tool Cutting Edge Angle (Degree) | 70 Degree |
| Corner Chamfer Angle (Degree) | 35 Degree |
| Point Angle (Degree) | 140 Degree |
| Material | Carbide |
| Product Type | Screw Machine Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Mill Diameter (Inch):
1/8"
Mill Diameter (Decimal Inch):
0.1240"
Mill Diameter (mm):
3.15mm
Shank Type:
Cylindrical
Material:
Carbide
Shank Diameter (Inch):
17/72"
Shank Diameter (Decimal Inch):
0.2362"
Shank Diameter (mm):
6.00mm
Overall Length (Inch):
2-3/5"
Overall Length (Decimal Inch):
2.5984"
Overall Length (mm):
66.00mm
