Product Specifications
| Manufacturer Part Number | 10188284 |
| Cutting Diameter (mm) | 3.00mm |
| Connection Diameter Machine Side (mm) | 4.00mm |
| Shank Diameter (mm) | 4.00mm |
| Shank Length (mm) | 27.00mm |
| Usable Length (mm) | 150.00mm |
| Overall Length (mm) | 188.00mm |
| Corner Chamfer Width (mm) | 0.10mm |
| Shank Type | Cylindrical |
| Coolant Entry Style Code | 4 |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 4 |
| Flute Helix Angle (Degree) | 40 Degree |
| Flute Helix Direction | Right |
| Tool Cutting Edge Angle (Degree) | 66.5 Degree |
| Corner Chamfer Angle (Degree) | 33 Degree |
| Point Angle (Degree) | 133 Degree |
| Material | Carbide |
| Product Type | Extra Long Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Related Products
Seco Tools
Seco Tools 10188290 | 3.00mm Diameter x 4.00mm Shank x 218.00mm OAL 30 Degree Helix Angle Carbide Extra Long Drill Bit
$1,450.00
$1,406.50
Seco Tools
Seco Tools 10188285 | 4.00mm Diameter x 4.00mm Shank x 240.00mm OAL 30 Degree Helix Angle Carbide Extra Long Drill Bit
$1,090.00
$1,057.30
Brand:
Seco Tools
Material:
Carbide
Overall Length (Inch):
7-13/32"
Overall Length (Decimal Inch):
7.4000"
Overall Length (mm):
188.00mm
Drill Point Angle:
133 Degree
Shank Type:
Cylindrical
interval quantity:
1
