Seco Tools 10270243 | R335.14-217100.12Z6-M03 21.70mm Cutting Diameter x 4.50mm Cutting Depth Maximum x 0.10mm Radius x 5.85mm Functional Length 6 Cutting Edge PVD Coated Carbide F32M Grade R335.14 Groove Milling Tip Insert

$103.20
Brand:
Seco Tools
Cutting Diameter (mm):
21.70mm
Finish/Coating:
PVD
SKU:
23346905
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10270243 | R335.14-217100.12Z6-M03 21.70mm Cutting Diameter x 4.50mm Cutting Depth Maximum x 0.10mm Radius x 5.85mm Functional Length 6 Cutting Edge PVD Coated Carbide F32M Grade R335.14 Groove Milling Tip Insert

Product Specifications
Manufacturer Part Number10270243
Cutting Diameter (mm)21.70mm
Contact Surface Diameter Machine Side (mm)12.00mm
Insert Rake Angle (Degree)16.00 Degree
Insert Rake Angle (Degree)16.0
Grade TypeCarbide PVD
Cutting DirectionRight Hand
Functional Length (mm)5.85mm
Corner Radius (mm)0.10mm
Peripheral Effective Cutting Edge Count6
Product SeriesR335.14
Product TypeGroove Milling Tip Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Seco Tools
Cutting Diameter (mm):
21.70mm
Finish/Coating:
PVD
