Seco Tools 10309510 | T30-PU08B06-1/2-13-21R UNC 1/2 - 13 Size x 2B Class x 0.500" Diameter x 0.355" Chamfer Length x 4.331" OAL 3 Flute Uncoated High Speed Steel-E Spiral Point Tap

$33.60
Brand:
Seco Tools
Class of Fit:
2B
Number of Flutes:
3
Cutting Direction:
Right Hand
Material:
High Speed Steel-E
interval quantity:
1
SKU:
23463659
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10309510 | T30-PU08B06-1/2-13-21R UNC 1/2 - 13 Size x 2B Class x 0.500" Diameter x 0.355" Chamfer Length x 4.331" OAL 3 Flute Uncoated High Speed Steel-E Spiral Point Tap

Product Specifications
Manufacturer Part Number10309510
Machine Side Connection Diameter (Decimal Inch)0.354"
Shank Diameter (Decimal Inch)0.354"
Functional length (Decimal Inch)3.976"
Usable Length (Decimal Inch)3.268"
Overall Length (Decimal Inch)4.331"
Recommended Premachined Hole Diameter (Decimal Inch)0.421"
Maximum Premachined Hole Diameter (Decimal Inch)0.434"
Tap Chamfer Length (Decimal Inch)0.355"
Thread Diameter (Decimal Inch)0.500"
Thread Diameter SizeUNC 1/2 - 13
Threading Chamfer Length (Decimal Inch)0.355"
Thread Length (Decimal Inch)0.945"
Minimum Threads per Inch (TPI)13.00 TPI
Maximum Threads per Inch (TPI)13.00 TPI
Threading Chamfer TypeB
Thread Form TypeUNC
Connection Size Code9.00 x 7.00
Machine Side Connection Size Code 9.00 x 7.00
Number of Flutes3
Basic Standard GroupDIN376
Shank TypeCylindrical
Thread Tolerance Class2B
Cutting DirectionRight Hand
MaterialHigh Speed Steel-E
Product TypeSpiral Point Tap

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
