Seco Tools 10309516 | T30-PU09B05-1/2-20-21R UNF 1/2 - 20 Size x 2B Class x 0.500" Diameter x 0.247" Chamfer Length x 3.937" OAL 3 Flute Uncoated High Speed Steel-E Spiral Point Tap

$33.60
Brand:
Seco Tools
Class of Fit:
2B
Number of Flutes:
3
Cutting Direction:
Right Hand
Material:
High Speed Steel-E
interval quantity:
1
SKU:
23463665
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10309516 | T30-PU09B05-1/2-20-21R UNF 1/2 - 20 Size x 2B Class x 0.500" Diameter x 0.247" Chamfer Length x 3.937" OAL 3 Flute Uncoated High Speed Steel-E Spiral Point Tap

Product Specifications
Manufacturer Part Number10309516
Machine Side Connection Diameter (Decimal Inch)0.354"
Shank Diameter (Decimal Inch)0.354"
Functional length (Decimal Inch)3.689"
Usable Length (Decimal Inch)2.874"
Overall Length (Decimal Inch)3.937"
Recommended Premachined Hole Diameter (Decimal Inch)0.453"
Maximum Premachined Hole Diameter (Decimal Inch)0.457"
Tap Chamfer Length (Decimal Inch)0.247"
Thread Diameter (Decimal Inch)0.500"
Thread Diameter SizeUNF 1/2 - 20
Threading Chamfer Length (Decimal Inch)0.247"
Thread Length (Decimal Inch)0.787"
Minimum Threads per Inch (TPI)20.00 TPI
Maximum Threads per Inch (TPI)20.00 TPI
Threading Chamfer TypeB
Thread Form TypeUNF
Connection Size Code9.00 x 7.00
Machine Side Connection Size Code 9.00 x 7.00
Number of Flutes3
Basic Standard GroupDIN374
Shank TypeCylindrical
Thread Tolerance Class2B
Cutting DirectionRight Hand
MaterialHigh Speed Steel-E
Product TypeSpiral Point Tap
