Product Specifications
| Manufacturer Part Number | 10309784 |
| Machine Side Connection Diameter (Decimal Inch) | 0.138" |
| Shank Diameter (Decimal Inch) | 0.138" |
| Functional length (Decimal Inch) | 2.150" |
| Usable Length (Decimal Inch) | 0.709" |
| Overall Length (Decimal Inch) | 2.252" |
| Recommended Premachined Hole Diameter (Decimal Inch) | 0.106" |
| Maximum Premachined Hole Diameter (Decimal Inch) | 0.108" |
| Tap Chamfer Length (Decimal Inch) | 0.052" |
| Thread Diameter (Decimal Inch) | 0.125" |
| Thread Diameter Size | UNF 5 - 44 |
| Threading Chamfer Length (Decimal Inch) | 0.052" |
| Thread Length (Decimal Inch) | 0.276" |
| Minimum Threads per Inch (TPI) | 44.00 TPI |
| Maximum Threads per Inch (TPI) | 44.00 TPI |
| Threading Chamfer Type | C |
| Thread Form Type | UNF |
| Connection Size Code | 3.50 x 2.70 |
| Machine Side Connection Size Code | 3.50 x 2.70 |
| Number of Flutes | 3 |
| Basic Standard Group | DIN371 |
| Shank Type | Cylindrical |
| Thread Tolerance Class | 2B |
| Helix Angle (Degree) | 40 Degree |
| Cutting Direction | Right Hand |
| Material | High Speed Steel-E-PM |
| Product Type | Spiral Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Shank Diameter (Decimal Inch):
0.1378"
Thread Diameter (Decimal Inch):
0.1250"
Thread Length (Decimal Inch):
0.2756"
Class of Fit:
2B
Thread Size:
UNF 5 - 44
Usable Length (Decimal Inch):
0.7087"
Overall Length (Decimal Inch):
2.2520"
Chamfer Length (Decimal Inch):
0.0520"
Helix Angle:
40 Degree
Number of Flutes:
3
Cutting Direction:
Right Hand
Shank Type:
Cylindrical
Material:
High Speed Steel-E-PM
