| Manufacturer Part Number | 10309787 |
| Machine Side Connection Diameter (Decimal Inch) | 0.866" |
| Shank Diameter (Decimal Inch) | 0.866" |
| Functional length (Decimal Inch) | 5.500" |
| Usable Length (Decimal Inch) | 3.347" |
| Overall Length (Decimal Inch) | 5.906" |
| Recommended Premachined Hole Diameter (Decimal Inch) | 1.161" |
| Maximum Premachined Hole Diameter (Decimal Inch) | 1.178" |
| Tap Chamfer Length (Decimal Inch) | 0.405" |
| Thread Diameter (Decimal Inch) | 1.250" |
| Thread Diameter Size | UNF 11/4 - 12 |
| Threading Chamfer Length (Decimal Inch) | 0.405" |
| Thread Length (Decimal Inch) | 1.063" |
| Minimum Threads per Inch (TPI) | 12.00 TPI |
| Maximum Threads per Inch (TPI) | 12.00 TPI |
| Threading Chamfer Type | B |
| Thread Form Type | UNF |
| Connection Size Code | 22.00 x 18.00 |
| Machine Side Connection Size Code | 22.00 x 18.00 |
| Number of Flutes | 4 |
| Basic Standard Group | DIN374 |
| Shank Type | Cylindrical |
| Thread Tolerance Class | 2B |
| Cutting Direction | Right Hand |
| Material | High Speed Steel-E |
| Product Type | Spiral Point Tap |
