Seco Tools 10339127 | WNMG060412-MR3 0.375" Circle Diameter x 0.187" Thickness x 0.047" Radius x 80 Degree Included Angle 6 Edge Count PVD Coated TS2050 Grade Carbide Turning Insert

$19.10 $14.13
(You save $4.97)
Brand:
Seco Tools
Thickness (Decimal Inch):
0.1874"
Corner Radius (Decimal Inch):
0.0472"
Material:
Carbide
interval quantity:
1
SKU:
23462522
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10339127 | WNMG060412-MR3 0.375" Circle Diameter x 0.187" Thickness x 0.047" Radius x 80 Degree Included Angle 6 Edge Count PVD Coated TS2050 Grade Carbide Turning Insert

Product Specifications
Manufacturer Part Number10339127
Fixing Hole Diameter (Decimal Inch)0.150"
Inscribed Circle Diameter (Decimal Inch)0.375"
Cutting Edge Length (Decimal Inch)0.256"
Cutting Edge Effective Length (Decimal Inch)0.240"
Corner Radius (Decimal Inch)0.047"
Insert Thickness (Decimal Inch)0.187"
Cutting Edge Count6
Chip Breaker Manufacturers DesignationMR3
GradeTS2050
Grade typeCarbide PVD
Insert Seat Size Code06
Insert HandNeutral
Insert Included Angle (Degree)80 Degree
CoatingPVD
MaterialCarbide
Product TypeTurning Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov
