Product Specifications
| Manufacturer Part Number | 75054856 |
| Cutting Diameter (Decimal Inch) | 0.812" |
| Cutting Diameter (mm) | 20.63mm |
| Connection Diameter Machine Side (Decimal Inch) | 0.750" |
| Connection Diameter Machine Side (mm) | 19.05mm |
| Shank Diameter (Decimal Inch) | 0.750" |
| Shank Diameter (mm) | 19.05mm |
| Functional Length (Decimal Inch) | 2.717" |
| Functional Length (mm) | 69.00mm |
| Protruding Length (Decimal Inch) | 2.717" |
| Protruding Length (mm) | 69.00mm |
| Shank Length (Decimal Inch) | 3.347" |
| Shank Length (mm) | 85.00mm |
| Overall Length (Decimal Inch) | 4.724" |
| Overall Length (mm) | 120.00mm |
| Maximum Depth of Cut (mm) | 7.00mm |
| Maximum Depth of Cut (Decimal Inch) | 0.276" |
| Rake Radial Angle (Degree) | -5 Degree |
| Rake Radial Angle (Degree) | -5 Degree |
| Rake Orthogonal Angle (Degree) | -5 Degree |
| Axial Rake Angle (Degree) | 5 Degree |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Rotational Speed (rpm) | 26200 rpm |
| Shank Type | Weldon |
| Product Type | Indexable Square-Shoulder End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Cutting Diameter (Inch):
13/16"
Cutting Diameter (Decimal Inch):
0.8122"
Cutting Diameter (mm):
20.63mm
Shank Type:
Weldon
Shank Diameter (Inch):
3/4"
Shank Diameter (Decimal Inch):
0.7500"
Shank Diameter (mm):
19.05mm
Overall Length (Inch):
4-21/29"
Overall Length (Decimal Inch):
4.7244"
Overall Length (mm):
120.00mm
